Barriers to Dust, Dirt, and Moisture
Filter and venting fabric materials can act as barriers to dust, dirt and moisture, protecting the components within a product while allowing air and sound to pass.
Acoustic Mesh
Acoustic Mesh is acoustically transparent while acting as a barrier to dust and moisture, protecting and extending the life of the device. Visit our Acoustic Mesh Page!
PTFE Vents for Pressure Equalization
Airflow through vents allows pressure to equalize within environmentally sealed enclosures (according to IP67) which protect the enclosure contents from damage. [Download IP Rating and NEMA Rating Charts]
Micro-sized Vents + Filters
Marian also has the advanced capabilities to manufacture extremely small filter and vent fabrics, down to 2 or 3mm in size.
Contact us for a material sample, a quote or a rapid prototype.
Precision Selective Lamination
During the die cutting process, Marian often laminates filter and mesh materials with pressure sensitive adhesive cut to a zone, leaving the central portion of the filter or vent free to breathe. Additionally, Marian can add layers of other thin materials to meet the desired function of the final part. Marian excels at precise selective adhesive lamination.
In the rendering above, final die-cut parts adhere to a liner on a roll which is used for automated placement within the customer’s assembly.
Applications
- Speaker covers
- Microphone covers
- Headphones
- Vents for sealed enclosures
- Sensor and microsensor (MEMS) venting membranes
- Breathable seals for automotive and outdoor lighting
- Air filtration
Materials
- Microporous PTFE Venting Membrane
- Filter mesh
- Acoustic mesh, Acoustic fabric
- Wire mesh materials
- Porous plastics and fibers
- Hydrophobic and Oleophobic materials
- Highly durable materials
DOWNLOAD – Success Story: Venting Solution for IP Rated Enclosure
The venting membrane disc die-cut by Marian allows air to enter the IP rated sealed compartment where the “brains” of the smart pallet are contained, while also protecting the sensitive components from harmful water, and dust debris.
Key Filter, Venting and Fabric Suppliers
